Multi-Use QR Code Scanner Continuous Scan 2D Handheld Bardcode
Scanner
DS6600 is a high-performance 2D barcode scanner with leading CMOS
image recognition technology.
It can easily read the paper, goods, screen and other media
barcodes. Widely used in manufacturing,
warehouse, logistics, health care, retail chain, mobile payment,
express delivery, inventory management,
food traceability, asset inventory,etc.
Features
☆ Ergonomic design, comfortable using.
☆ Read all mainstream1D&2D barcodes in the market easily.
☆ High-performance processor, fast decoding. (4mil)
☆ Support multiple languages and systems.
☆ Interface: USB,RS232
☆ Support USB barcode information transmission. ( languages
customization)
☆ Widely used in supermarket, warehouse, mobile payment, chain
stores.
Application
| ▅ Supermarket | ▅ Warehouse |
| ▅ Mobile payment | ▅ Retail chain |
| ▅ Courier | ▅ Health care |
Performance
| Scan Type | CMOS |
| Light Source | Red Light LED 625±10nm(aim), 5600K LEDs( Lighting) |
| CPU | 32-bit |
| Resolution | 640*480 |
| Resolution | ≥4mil/0.1mm(PCS90%,Code 39) |
| Decoding speed | 25CM/S |
| Depth of field | 0mm-500mm |
| Scan Mode | Manual ,Continuous, Auto Sense |
| Scan angle | Test Conditions:CODE39,10mil/0.25mm,PCS90% |
| Pitch:±65°,Roll: ±360°,Skew: ±60° |
| Print Contrast Signal | ≥25% |
| Ambient Light | Dark environment, indoor natural light |
| Symbologies | 1D: UPC-A,UPC-E,EAN-8,EAN-13,ISSN,ISBN,Code 128, GS1-128,ISBT 128,
Code 39,Code 93,Code 32, Code 11, Interleaved 2 of 5,Matrix 2 of
5,Industrial 2 of 5,Standard 2 of 5(IATA),Codabar(NW-7),Plessey,MSI
Plessey,GS1-Databar(RSS),Itf-14,etc. 2D: QR Code, Data Matrix, PDF 417, Aztec Code, Maxicode, Hanxin.
etc. |
Physical Parameter
| Weight | ≈110g(without cable) |
| Dimension | L180mm * W60mm * H80mm |
| Communication Mode | USB(USB-KBW,USB-COM),RS232 |
| Interface Type | USB ,DB9 |
| Power Supply | DC 5V@120mA(work) |
FQA:
Q1: How do you make sure the high quality barcode scanner?
DYscan: we are pofessional manufacturer and developer of barcode
scanner, with rich field experience for 18 years.
Professional QC team and testing machine (Engine age test,wire bend
machine,switch life test,shock resistance test).
All our barcode scanners pass CE,FCC,ROSH certifications etc.
Q2: How do you make quality control?
DYscan: we have wire bend test 1 million times, buttons are tested
1 million times, all the devices will be tested before send out.
Q3: How long is the warranty time of barcode scanner?
DYscan: 12 months
Q4: How to control the performance stable?
DYscan: We take the flow line production in the whole processing.
Every product will be tested 4 times at least before delivery.
Q5: Can you provide OEM or ODM service for barcode scanner?
DYscan: We can do OEM, such as printing your own logo, color box,
user manual. And we have our own technical team to support ODM
service.
